Features

  • Diversity
  • Tone control squelch
  • Working range adjustable
  • Full metal design
  • LCD display
  • 16 channels selectable

Contents

  • Receiver
  • 6.3mm Mono cable
  • DC Power Supply
  • 2x Detachable antenna

Specifications

.rpg_table { border-collapse: collapse } .rpg_table th, .rpg_table td { padding: 5px; } .rpg_table td, .rpg_table th { text-align: left; vertical-align: top; border-top: solid 1px #cccccc; border-bottom: solid 1px #cccccc; } .rpg_table th, .rpg_table .header { font-weight: bold; text-align: left }
System
Carrier frequency UHF 654-694 MHz
Stability ± 0.005% (at 25°C)
Ambient temperature -10°C ~ +50°C
Max deviation ± 70KHz with level limiting
Dynamic range 110dB
S/​N ratio >110dB
T.H.D. >0.5%
Pre/​De-Emphasis 50µs
Squelch Tone control and noise lock dual squelch
Frequency response 30Hz – 20KHz
Operating range 100m (approximately 300′) under typical conditions
Receiver
Receiving mode PLL Single Dual channel receiving
Sensitivity >-107dB
Image rejection Over 80dB
Audio output Unbalanced, Hi Z-360mV/​10K Mixer
Power requirement AC 110-120V/​220-240V (50-60Hz)
External 10-18VDC / 1A
Dimensions
(D x W x H) 		192 x 220 x 39mm
Weight Approx.1.5kg
