DOME20 600TVL SECURITY DOME CAMERA
Discontinued
Features
- 1/3" Sony Super HAD II CCD
- Nextchip NVP2040
- 600TVL Resolution
- 4mm – 9mm Varifocal Korean lens
- 10m – 15m IR Range





Specifications
Model | DOME20 |
Sensor |
1/3" Sony Super HAD II CCD |
DSP | NVP2040 |
Resolution | 600TVL |
Effective Pixels | NTSC: 768 x 494 PAL: 752 x 582 |
Lens | 4mm – 9mm |
Lens Type | Manual |
Lens Origin | Korea |
Approx View Angle (H) | 98° – 38° |
IP Rating | IP65 |
IR LEDs | 18x Ø5mm |
IR Range | 10m – 15m |
Adjustable IR Brightness | no |
WDR (Wide Dynamic Range) |
none |
Sens-up | no |
OSD | yes |
Inline Controller | no |
Noise Reduction | 2D-NR |
Backlight Compensation | HLC/BLC/OFF |
Image Colour Adjustment? (ie brightness/contrast/ tone/saturation/sharpness) |
yes |
Mirror function (Horiz / Vert / Rotate) |
H |
Privacy Zones | 8 |
Motion Detection Zones | 4 |
RS-485 | no |
Power (with IR on where applicable) |
12VDC / 400 mA |
About Sony Chipsets
![]() |
||
Sony’s Super HAD CCD II offers improved characteristics over the Super HAD CCD Sensor and other CCD Sensors.
|
||
![]() |
||
![]() |
Microlens Structure |
![]() |
Other CCD Sensors | Sony Super HAD II CCD | |
