DM30IPW4M DOME 2.8-12MM LENS 4MP 30M IR POE IP CAMERA – WHITE

DM30IPW4M DOME 2.8-12MM LENS 4MP 30M IR POE IP CAMERA – WHITE

Additional Images

43160602

Features

  • Max resolution 4Mega(2592×1520 @ 20fps)

    Support low bit rate, low delay and ROI enhance encoding

    H. 265 high effective compression, save bandwidth and storage space

    Support multi-line OSD, OSD color can be
    adjusted

    High efficient infrared leds, long service life,IR distance can reach 25-30m

    Support Smart IR, prevent IR overexposure at night

    ICR infrared filter plate automatic switch, achieve real D/N monitoring

    Support corridor mode, increase the monitoring area in longitudinal strip environment

    Support Micro SD card (128G) local-storage

    Support 3D digital N/R,DWDR

    Support auto electronic shutter function,adapt different monitoring environment

    Support GB28181, Onvif access

    Support Email, NTP, HTTPS encryption transmission

High Resolution – See more!



Specification

CAMERA
Image sensor 1/3" 4MP Progressive Scan CMOS
Min.illumination 0Lux/F1.4(IR on)color: 0.5Lux/F1.4, B/W:0.2Lux/F1.4
IR distance 25-30M(2xIR-III Leds)
Electronic shutter Auto/Manual(1/25~1/10000), FLK
Day/Night ICR switch, auto, color, B&W, ext
Lens 2.8-12mm motorised lens
Lens interface F14
S/N ratio =35db (AGC OFF)
Output  PAL/NTSC adjustable
WDR DWDR(Off/Low/Middle/High)
Light board control Auto/Manual/Off
3D N/R Off/Low/Middle/High/Higher
Defog Off/Low/Middle/High
Mirror Off/Horizontal/Vertical/180º rotation/Corridor mode (90º rotation,270º rotation)
Slow Shutter Off/On
Exposure control Auto/ Manual
Image setting Brightness, Contrast, Saturation, Sharpness, Hue
AUDIO/VIDEO ENCODING
Video compression H.265/ H.264/ MJPEG
H.265 Encoding  Main Profile
H.264 Encoding  BaseLine/Main Profile/High Profile
Encoding features NTSC: main stream: 2592*1520 @20fps/2560*1440@25fps, sub-stream: VGA@30fps

Max. Resolution 4M(2592X1520)
Video bit rate Constant bit rate, variable bit rate (16kbps~8000kbps)
Video type Complex stream/ Video stream
Audio compression /
Audio bit rate /
Audio control Support input/ output volume gain control
ROI  Support 4 zones,multi-stage level
Watermark function /
NETWORK
Network protocol TCP/IP, UDP, HTTP, DHCP, RTSP, DDNS, NTP, PPPoE, UPnP, SMTP
Access protocol ONVIF,GB28181 (optional)
Browser Support IE, Chrome, Firefox, Safari
Video preview meanwhile 4
User permission User add/modify/delete, permission
management
Safe mode Authorized user name and password, HTTPS encryption and AES link encryption, RTSP verification
Motion detection Set detection zone, Multi-level sensitivity can be set
Tampering alarm 1 zone
Privacy Mask 4 zones
Intelligent analysis Target Counting, Area Detection, Left/Lost, Line Crossing
Event linkage Email sending, alarm output linkage, preset linkage
Multicast function Support
ANR /
Mobile surveillance Support Apple, Android
Device exception detection Support network disconnected, IP conflict, illegal access alarm
OSD Title, time and date overlay, multi-line OSD, OSD colour optional
DST Support
Snapshot Support snapshot, snapshot resolution is encoding resolution
System update Support remote update
Other /
INTERFACE
Network Interface RJ45 10M/100M network adaptive
Analog video output 1CH 1.0Vp-p Composite video output
Audio  /
Alarm input /
Alarm output /
Reset Support
RS485 /
TF card Support Max 128G, Micro SD(SDHC /SDXC) card local-storage
Other /
GENERAL
Operating temperature -20°C ~ 55°C
Operating humidity 0?-90?
Protection grade IP66
Power supply DC12V/PoE optional
PoE   Optional
Power consumption (max) <9W
Dimensions(mm) 120x97mm
Weight/PCS(g) /
