The DOSS IP cameras are the next step in CCTV technology allowing you to install a complete system using an conventional, economical ethernet network. Features like Power over Ethernet and BNC analogue video output make it a breeze for installers. ONVIF compliance allows integration with compatible Networked Video Recorders, no matter the brand, for centralised video capture and back-up.

  • 1/​2.8" Sony 2.43 Mega Pixels low illumination CMOS Sensor
  • H.264 encoding
  • 1080P (Full HD) resolution
  • Conforms to ONVIF (Open Network Video Interface Forum) protocols, Profile-S/​G
  • Supports Power Over Ethernet (PoE)
  • Analog BNC output for installers
  • 2.8-12mm lens
  • 20-30m IR distance / 2x IRIII IR Leds
  • Dual stream
  • Privacy zone
  • IP66
  • DC12V with PoE
  • Black Colour

Specifications

Model IN30IPW2
Camera Sensor 1/​2.8" Sony CMOS
Pixel Count 2.43MP
DSP Hi3516C
Resolution 1920×1080
Lens 2.8-12mm (2MP)
Lens type
(fixed / varifocal:auto / manual) 		Varifocal – Manual
Day/​Night ICR
(Infrared Cutfilter Removal) 		Auto / B / W / Colour / EXT ICR switching
Approx view angle (Horiz) approx 83°
Minimum illumination 0 Lux / F1.4 (IR On)
Electronic shutter Auto / Manual
(1/​25 ~ 1/​10000)
Encoding Stream 1 resolution Up to
PAL: 1080P / 25fps
NTSC: 1080P / 30fps
Stream 1 Encoding h.264 / MJPEG
Stream 1 Bitrate 16~8000kbps
CBR / VBR
Stream 2 resolution Up to VGA (640*480)
Stream 2 Encoding h.264 / MJPEG
Stream 2 Bitrate 16 ~ 8000kbps
CBR/​VBR
Audio compression G.711A
64kbps
Features Analogue output Yes (BNC, CVBS)
IP Rating IP66
IR LEDs 2x IR Array Leds
IR Range 20 – 30m
Adjustable IR Brightness NO
WDR
ATR / D-WDR 		DWDR
Noise Reduction
(none / 2D-NR / 3D-NR) 		3D-NR
Image adjustment
(Brightness / Colour / Sharpness) 		Brightness / Sharpness
Image flip (H / V / H+V) H / V / H+V
Privacy zones 4
Motion detection zones 1
Password protection Yes
OSD (Channel/​Timestamp) Yes (Channel / Timestamp)
Alarm Video loss / Network loss / Tamper
Power over Ethernet Yes (IEEE 802.3 STANDARD)
Networking ONVIF Compliance Profile S (v2.2)
Protocols supported TCP / IP, UDP, HTTP, DHCP, RTP/​RTSP, DNS, DDNS, NTP, PPPoE, UPnP, SMTP
Network interface RJ45 10M / 100M
Remote viewing Web-browser / Apple / Android
General Operating Conditions −10°C ~ 55°C / 0%~90%RH
Power Supply DC12V / PoE (IEEE 802.3 AF standard)
Power Consumption <6W
Dimensions (ØxH / W x H x L) Ømm
Weight 800g
