Features

  • Distributes 1 SDI input signal to 2 SDI outputs simultaneously
  • Work as repeater to transmit up to 120m
  • Re-clocking function capability— unlimited repeater connection
  • Support SDI Standard: SD-SDI, HD-SDI, 3D-SDI
  • Data Rates: 270Mbps (SD-SDI), 1.485Gbps (HD-SDI), 2.97Gbps (3G-SDI)
  • DC 5V~12V (Power consumption less than 2W)

Specifications

Re-clocking Function

Yes

SDI Standards

SD-SDI, HD-SDI,3G-SDI

HD/​SD-SDI Detection

Auto

Supported Protocols

SMPTE 259M
SMPTE 292M
SMPTE 424M

Data Rates

270Mbps (SD-SDI), 1.485Gbps (HD-SDI), 2.97Gbps (3G-SDI)

Video Support

480i @ 60Hz, 720p @ 50 / 59.94 / 60Hz, 1080i @ 50 / 59.94 / 60Hz, 1080p @ 23.98 / 24 / 25 / 29.97 / 30 / 50 / 59.94 / 60Hz

SDI Signal Type

SMPTE-292M, SMPTE-259M, SMPTE-424M

Output Impedance

75 ohms

Cable Equalization

HD-SDI up to 120m
SD-SDI up to 200m
Unlimited repeater connection

Audio Sampling rate

48Khz

Impedance

75 ohms

Input

1x BNC [SDI]

Output

2x BNC [SDI]

Power Adapter

5V~12V DC

Power Consumption (Max)

2W

Operating Temperature

0°C ~ 40°C

Storage Temperature

-20°C~ 60°C

Relative Humidity

20~90% RH (no condensation)

Housing Material

Metal case
