Features

CCTV Calculator Calculate everything!
  • 1/​3" Sony EXview HAD II CCD
  • Sony EFFIO-E
  • 700 TVL Resolution
  • 20m – 30m IR Range
  • Approx 62° Horizontal view


Download the latest DOSS CCTV Cameras Sellsheet

Specifications

Sensor

 1/​3" Sony EXview HAD II CCD
DSP Sony EFFIO-E
Resolution 700 TVL
Effective Pixels NTSC: 976 x 494
PAL: 976 x 582
Lens 6mm
Lens Type Fixed
Lens Origin China
Approx View Angle (H) 62°
IP Rating IP66
IR LEDs 36x Ø5mm
IR Range 20m – 30m
Adjustable IR Brightness no
WDR (Wide Dynamic Range) no
Sens-up no
OSD no
Inline Controller no
Noise Reduction no
Backlight Compensation no
Image Colour Adjustment?
(ie brightness/​contrast / tone/​saturation/​sharpness) 		no
Mirror function
(Horiz / Vert / Rotate) 		no
Privacy Zones no
Motion Detection Zones no
RS-485 no
Power
(with IR on where applicable) 		12VDC / 450mA
Dimensions (excluding mount) 135Lx78Wx77H

About Sony Chipsets

Sony’s EXview HAD CCD II offers improved characteristics over the Super HAD CCD II and EXview HAD CCD Sensors, andother CCD Sensors.

  • Less space between On-chip microlenses and lightsensors
  • Improved and longer life colour filters
  • Larger light sensors and larger sensor apertures
    • Higher light sensitivity and improved spectral sensitivity
    • High sensitivity to near IR range
    • Lower noise
  • Reduced image Smearing
Microlens
Structure
Low light
& IR sensitivity
Smear
Other CCD Sony EXview HAD II CCD

New in 2013, the DOSS range of cameras are being upgraded with Sony Effio DSP (Digital Signal Processor) chipsets for superior images and features—first and foremost, introducing 700TVL resolution across our range!

Sony’s Effio-E DSP Chipset supports the following features*:

  • Entry-level Effio technology
  • ATR (Adaptive Tone Reproduction)
  • 2D noise reduction
  • Motion detection
  • Privacy mask
  • HLC (High Light Compensation)
  • Preset OSD
  • Exposure control for IR light
  • Low power consumption
*Features mentioned are supported by Effio chipset but may not be implemented/​enabled – please check the camera specifications.
