Features

  • Sixteen port power supply
    • Output current: 0.5A (Max) per port
  • Built in "no fuse breaker" to avoid current overload
  • Built in PTC (positive temperature coefficient) on each port for short protection and auto reset
    • Fault on one port does not affect others
  • Switch-mode power supply allows wide range of voltage input and disturbance tolerance

Specifications

  • Output Port: 16
  • Output Voltage: DC12V REGULATED
  • Output Current: 0.5Amp per Port
  • Output Trip Current: 1A/​Port
  • Short-circuit Cut Time: 0.2 Sec/​Port
  • Over Current Cut / Time: 2.5A/​4Sec
  • Resetable Output: Auto
  • Resetable Output Time: 1 Sec (Min)
  • Dimensions:
    • 437×170×44 mm
    • 1RU height
  • Storage temperature: -30°C~70°C
  • Operating temperature: -10°C~45°C
  • Weight: 4kg
