Suits UHF101 and UHF401 (UM401) Receivers

  • Working range adjustable
  • 16 channels selectable

Specifications

System
Carrier frequency UHF 654-694 MHz
Stability ± 0.005% (at 25°C)
Ambient temperature -10°C ~ +50°C
Max deviation ± 70KHz with level limiting
Dynamic range 110dB
S/​N ratio >110dB
T.H.D. >0.5%
Pre/​De-Emphasis 50µs
Squelch Tone control and noise lock dual squelch
Frequency response 30Hz – 20KHz
Operating range 100m (approximately 300′) under typical conditions
Microphone
Type Dynamic microphone
Antenna Built-in
RF output 15mW
RF output 45dBc
Battery Two 1.5V AA battery or 1.2V AA rechargeable battery
Battery life 8 Hours
Dimensions Ø52 x 240mm handheld
Safety Approvals FCC, CE
Weight 260g
