Features

  • Designed to support high speed data network applicationssuch as 10-Gigabit Ethernet (10GBASE-T)
  • 4 Pairs and a drain wire
  • Minimise alien crosstalk
  • Excellent signal isolation and EMI protection

Specifications

Conductor Material Bare Copper
Size 23AWG
1/​0.56/​0.58±0.015mm
Insulation Material HD-PE
Thickness MIN at any point: 0.24 / 0.28mm
MAX AVG: 0.26/​0.3mm
Diameter 1.08±0.01mm; 1.15±0.01mm
Colour Code Blue / White-Blue
Orange/​White-Green
Green / White-Green
Brown / White-Brown
Elongation MIN 300%
Tensile strength MIN 1.682 Kg/​mm2
Stranding Myar 0.025x23mm
Al Foil 0.065x23mm
Drain Wire 1/​0.40±0.02mm
Cross Slot 5.0×0.7mm
Jacket Material CMR PVR
Thickness MIN at any point: 0.53mm
MAX AVG: 0.57mm
Diameter 7.4±0.2mm
